User Environment
ESD: 8KV continuous contact discharge; 15KV from air to all surfaces without contact
Humidity: 95% relative humidity (non-condensing)
Drop: Unit functions normally after 4ft (1.2m) drop to concrete
Power Supply: 90V - 230VAC, 50/60Hz
Output: 15VDC, 5A or 24VDC, 4.5A
Safety Standards
Charger and power supply UL listed (UL1950), CSA Certified (C 22.2 No. 223): Compliant to FCC part 15 Class A and CE Marking (Electromagnetic Compatability) Directive 89/336/EEC and Low Voltage Directive 73/23/EEC; C15PR-22 Class B
Performance Characteristics
Rapid Charging: Charges batteries to 90+% capacity in 2 hours or less
Complete Charge: Completes 100% capacity charge in 4 hours or less
Conditioning: Completely discharges battery and automatically switches to charging mode
Maintenance Charge: Maintains battery at optimum capacity indefinitely
User Interface
Power LED: Indicates POWER to charging slot
Conditioning/ Charging LED: Flashing indicates discharging process; Solid indicates battery pack is charging
Reject LED: Flashing indicates faulty battery
Ready LED: Solid indicates battery charged
Environmental
Storage: -40 - 122oF (-40 - 50oC)
Operating: 32 - 122oF (0 - 50oC)
Dimensions
13 x 1.7 x 7in (WxHxD)
(330 x 45 x 178mm)
Weight
4lbs (1.5kg)
